Specification
Working Principle
◎ The power is through the crank linkage mechanism, the rotational motion of the crankshaft is transformed into the reciprocating movement of the plunger;
◎ When the plunger retreats, due to vacuum suction, the inlet valve opens and the outlet valve closes, and the water is sucked into the cylinder;
◎ When the plunger advances, due to the increase in the water pressure in the pump, the inlet valve is closed, the outlet valve is opened, and the high-pressure water is discharged from the outlet valve through the high-pressure pipe;
◎ The pump pressure is established depending on the size of the damping at the outlet of the pump, and the damping is high and the pressure is low;
Application
◎ Desalination of Seawater;
◎ Pharmaceutical;
◎ Chemical Industry;
