Description
Specification
◎ Voltage: 12VDC
◎ Ambient Temperature: 0 ~ 40℃
◎ Relative Humidity: ≤ 90%
Liquid Pump
◎ Load Current: ≤ 210mA
◎ Flow Rate Of The Max Pumping Height: 85 mL/min
◎ Max Pumping Height: 1.5 mH2O
◎ Flow Rate Of The Max Drainage Height: 230 mL/min
◎ Max Drainage Height: 2 mH2O
◎ Media Temperature: 5 ~ 50℃
Vacuum Pump
◎ Load Current: ≤ 140mA
◎ Average Flow: 0.4 L/min
◎ Relative Vacuum: -13kPa
◎ Media Temperature: 0 ~ 50℃
Feature
◎ Brushless motor, low electromagnetic interference.
◎ Oil-free pump, no pollution transmission.
◎ Maintenance-free and corrosion-resistant.
Application
◎ Medical Equipment;
◎ Environmental Detection;
◎ Experimental Equipment;
◎ Food Chemical Industry;
Micro DC Vacuum Pump 12V Diaphragm Pump WUY280A Industry/Experiment Equipment Water And Air Dual-use
$49.99
