Micro DC Vacuum Pump 12V/24V Diaphragm Pump WNY1000A Industry/Experiment Equipment Water And Air Dual-use

$125.99

size: DC12V

DC12V
DC24V
Add to Wishlist

visamasteramazon paymentsamerican expressapple paypaypal
Description

Specification
◎  Voltage: 12VDC , 24VDC
◎  Ambient Temperature: 0 ~ 40℃
◎  Relative Humidity: ≤ 90%

Liquid Pump
◎  Load Current: ≤ 500mA , ≤ 280mA
◎  Flow Rate Of The Max Pumping Height: 400 mL/min
◎  Max Pumping Height: 3 mH2O
◎  Flow Rate Of The Max Drainage Height: 280 mL/min
◎  Max Drainage Height: 5 mH2O
◎  Media Temperature: 5 ~ 50℃

Vacuum Pump
◎  Load Current: ≤ 380mA , ≤ 220mA
◎  Average Flow: 0.9 L/min , 1.1 L/min
◎  Relative Vacuum: -27kPa
◎  Media Temperature: 0 ~ 50℃

Feature
◎  Brushless motor, low electromagnetic interference.
◎  Oil-free pump, no pollution transmission.
◎  Maintenance-free and corrosion-resistant.

Application
◎  Medical Equipment;
◎  Environmental Detection;
◎  Experimental Equipment;
◎  Food Chemical Industry;
