Specification
◎Medium: Water, Polyurethane, Gasoline, Glue And Other Weakly Corrosive Liquids
◎Accuracy: ±0.5% (High viscosity accuracy up to 0.2%)
◎Output: Hall & Reed Tube Pulse Output
◎Power Supply: 4 ~ 26VDC
◎Temperature: -30 ~ 80°C
◎Pressure: 32Bar
◎Material: SS316L (Housing, Gear, Bearing)
◎Range Ratio: Min (1:100), Max (1:200)
Parameter
◎CX-M2 (Flow: 0.5 ~ 150ml/min, Connection: G1/8" Female Thread, Pulse Coefficient: 0.06ml/P)
◎CX-M3 (Flow: 3 ~ 300ml/min, Connection: G1/8" Female Thread, Pulse Coefficient: 0.14ml/P)
◎CX-M5 (Flow: 5 ~ 1000ml/min, Connection: G1/8" Female Thread, Pulse Coefficient: 0.36ml/P)
◎CX-M6 (Flow: 0.5 ~ 100L/min, Connection: G1/4" Female Thread, Pulse Coefficient: 1ml/P)
◎CX-M9 (Flow: 6 ~ 600L/min, Connection: G1/4" Female Thread, Pulse Coefficient: 5ml/P)
Application
◎Semiconductor Industry;
◎Environmental Protection;
◎Leak Testing;
◎Petrochemical;
◎Chromatograph;
◎Polyurethane Industry;
◎Lubrication System;
◎Ethanol System;
