1 Sec. Quick Respon 4-20ma 2 Way 24VAC/DC CF8 Proportional Integral Control Motorized Ball Valve

$318.99

size: 1 inch

1 inch
1-1/4 inch
1-1/2 inch
2 inch
2-1/2 inch
Add to Wishlist

visamasteramazon paymentsamerican expressapple paypaypal
Description
Product Overview:

Safer And More Durable: Safety And Reliability Are Our Core Commitments. Pressure-Tested, Rugged And Wear-Resistant CF8 With A Smooth, Burr-Free Surface And A Service Life Of Up To 2,000 Cycles, This Product Is The Best Choice For Your Industrial Control;
Fast Response And Precision: We Are Proud To Introduce This Revolutionary Control Valve In The Industrial Sector Where Efficiency And Precise Control Are Required. With An Astonishing 1-Second Response Time, It Brings Unprecedented Precision And Control To Your Industrial Applications. Whether It's Quick Opening Or Closing, It's Easy To Handle And Ensure A Smooth Production Process;
Ensure Safety Accuracy: Built-In High-Performance Brushless Motor Control Module, Accurate Positioning Through Frequency Speed Regulation, And Internal Motor Overload Protection To Ensure Safety And Stability During Operation. Its High-Precision Position Control Function Can Be Set By Software To Achieve An Accuracy Of ±1%, Which Meets Your Strict Requirements For Precise Control;
Easy To Connect And Adapt: This Product Has BSPP Or NPT Standard Threads, Which Can Be Easily Connected According To ISO5211 F03/F04/F05 Standards, And Can Meet The Effective Connection Needs In Most Scenarios. An Ideal Alternative To Solenoid Valves, It Automatically Shuts Off Power After Full Or Full Shutdown To Prevent Overheating, And Is Suitable For Secondary Valve Models In A Wide Range Of Projects, Demonstrating Its Superior Performance And Flexibility;




Product Detail:
◎ Valve Dimension: 1" 1-1/4"1-1/2" 2" 2-1/2"   BSPP or NPT Thread Available;
◎ Switching Time: 1 Sec.
◎ Actuator Rated Torque: 20N.m;
◎ Recomand Install Below 15N.m Valvd Body;
◎ Rated Voltage: 24VAC/DC;
◎ Position Feedback: 4-20mA;
◎ Position Accuracy: ±1%(Set By Software);
◎ Adopted High-Performance Brushless Motor, Overload Protection of Internal Motor;
◎ It can be used 20,000 times.*1;
◎ Connection Standard: ISO5211 F03/F04/F05;
◎ Valve Body: Stainless Steel
◎ Seat:EPDM
◎ Valve Plate:Stainless Steel
◎ Valve Shaft:416
◎ Shaft Sleeve:EPDM
◎ O-Ring:EPDM

Electrical Data:
◎ Rated Voltage: AC/DC24V (AC18-28V; DC18-32V);
◎ Power Consumption: 85W @Running, 1w@Holding;
◎ Peak Current:950mA@5ms;
◎ Connecting Cable: 7*0.2mm² Cable, Voltage Withstand AC300V;
◎ Fuse: 2A;

Functional Data:
◎ Rated Torque: 20N.m;
◎ Angle Of Rotation: 90°±2°;
◎ Max Angle Of Rotation: 330°±5°;
◎ Manual Operation: ※ Matching Hexagon Wrench, Wsing At No Power;
◎ Running Time: About 10S(Per 90°);
◎ Continuous Running: Continuous Running;
◎ Sound Power Level: Max 50dB(A);
◎ Position Indicator: Mechanical and Screen;

Working Conditions:
◎ Electricity Safety Level: III Type (Safety Low Voltage);
◎ Inflaming Retarding Level: V0 UL94 Test Method;
◎ Enclosure: IP67 As Per En60529/GB4208-2008(All Directions); F Type Can Add Dehumidifying Heater ;
◎ Insulation Resistance: 100MΩ/500VDC ;
◎ Withstand Voltage: 500VAC, 1Min;
◎ Medium Temperature: ≤80° Can Install To Actuator Directly; >80° Need To Install Bracket or Heat Radiation Stand;
◎ Indoor or Outdoor; If Exposed To The Rain or Sunshine, Need To Install Protective Device For The Actuator;
◎ Not Explosion Proof Products, Do Not Use Them in Flammable and Explosive Environment;
◎ Ambient Temperature: -30℃ ~ 60℃;
